1/8-27 NPT 4F RHSF HSS-E OX
Additional Tariff Surcharge of 5 %
| Thread Diameter Size (TDZ) | 1/8″ | Coolant Supply Property (CSP) | External |
| Threads per Inch (TPI) | 27 | Cutting Direction (HAND) | Right Hand |
| Thread Standard | NPT | Chamfer | 2.5P-3.5P |
| Flute Count (NOF) | 4 | Coating | Black Oxide |
| Overall Length (OAL) | 2-1/8″ | Cutting Edge Material | HSSCo |
| Thread Cutting Part Length (THL) | 3/4″ | Standard | ANSI |
| Connection Diameter Machine Side (DCONMS) | 7/16″ | Thread Size | 1/8″ - 27 |
Product Features
| Country of Origin | DE |
Shipping Info
Package Weight
.0613
