| Thread Diameter Size (TDZ) | M14 | Thread Tolerance Class (TCTR) | D6 |
| Thread Pitch (TP) | 1.5 mm | Chamfer | 2-3 Form C |
| Thread Standard | Metric Fine | Coating | TiCN |
| Overall Length (OAL) | 3.5906″ | Flute Length | 0.5906″ |
| Thread Cutting Part Length (THL) | 0.590″ | Flute Type | Spiral |
| Connection Diameter Machine Side (DCONMS) | 0.429″ | Style | Semi-Bottoming |
| Flute Count (NOF) | 3 | Coolant Supply Property (CSP) | External |
| Flute Helix Angle (FHA) | 40 Degrees | Measurement Type | Metric |
| Cutting Edge Material | HSS-E | Series/List # | 4414 |
Product Features
| Country of Origin | DE |
Shipping Info
Package Length
4.00000
Package Width
1.00000
Package Height
1.00000
Package Weight
.136
