| Cutting Diameter (DC) | 7/16″ | Shank Type | Taper |
| Usable Length (LU) | 1-3/4″ | Flute Type | Straight |
| Overall Length (OAL) | 7″ | Length Chip Flute (LCF) | 1-3/4″ |
| Cutting Direction (HAND) | Right Hand | Measurement Type | Inch |
| Flute Helix Angle (FHA) | 0 Degrees | Decimal Equivalent | .4375 |
| Cutting Edge Material | Carbide |
Product Features
| Remarks | •Carbide Tipped Chucking Reamers •Carbide tips brazed to one-piece hardened tool steel bodies. Cutting diameter tolerance +.0003 .0000 . For general reaming of steel, cast iron, non-ferrous metals, plastics and non-metals. Reamers for steel have a special cutting geometry; positive radial rake (behind center) narrow circular lands; minimum back taper & longer flutes for straighter holes. | Country of Origin | UNITED STATES |
Shipping Info
Package Weight
.438
